Easy-Setup HVLP Gravity Feed Spray Gun
Built for straightforward setup and controlled spraying, this pneumatic HVLP gun is suitable for automotive refinishing, furniture, cabinets, metal projects and DIY workshop use. The adjustable controls and 600cc metal cup make it practical for repeated coating tasks.
Product Attributes & Specifications
| Attribute | Details |
|---|
| 1. Product Category | Pneumatic paint spray gun |
| 2. Model | H-827P |
| 3. Spray Technology | HVLP |
| 4. Feed Method | Gravity feed |
| 5. Cup Capacity | 600 cc |
| 6. Cup Material | Metal |
| 7. Nozzle Choices | 1.4 / 1.7 / 2.0 / 2.5 mm |
| 8. Nozzle Feature | Interchangeable sizes |
| 9. Spray Pattern 1 | Vertical fan |
| 10. Spray Pattern 2 | Horizontal fan |
| 11. Spray Pattern 3 | Round pattern |
| 12. Pattern Adjustment | Adjustable control knob |
| 13. Paint Flow | Adjustable |
| 14. Air Flow | Adjustable |
| 15. Air Inlet | G1/4 inch |
| 16. Air Consumption | 2.5–3.5 CFM |
| 17. Working Pressure Spec | 3.5 bar / 50 PSI shown in specification image |
| 18. Common Setup Range | 20–30 PSI at gun inlet for many projects |
| 19. Overall Height | Approx. 305 mm / 12.01 in |
| 20. Gun Length | Approx. 125 mm / 4.92 in |
| 21. Cup Width | Approx. 100 mm / 3.94 in at top |
| 22. Cup Height Section | Approx. 135 mm / 5.31 in |
| 23. Front Head Dimension | Approx. 45 mm / 1.77 in |
| 24. Recommended Distance | 15–20 cm / 6–8 in |
| 25. Recommended Overlap | About 50% between passes |
| 26. Atomization | Fine atomization |
| 27. Coverage | Even spray coverage |
| 28. Finish Quality | Designed for smooth finish work |
| 29. Power Source | Compressed air |
| 30. Operating Control | Manual trigger |
| 31. Handle | Textured pistol grip |
| 32. Visible Finish | Red/blue body with metallic components |
| 33. Paint Preparation | Filter paint before spraying |
| 34. Viscosity Range | Most low-to-medium viscosity coatings |
| 35. Automotive Paint | Suitable |
| 36. Primer | Suitable |
| 37. Clear Coat | Suitable |
| 38. Enamel | Suitable |
| 39. Lacquer | Suitable |
| 40. Urethane | Suitable when coating instructions allow |
| 41. Automotive Refinishing | Suitable application |
| 42. Furniture Painting | Suitable application |
| 43. Cabinet Painting | Suitable application |
| 44. Woodworking | Suitable application |
| 45. Metal Projects | Suitable application |
| 46. DIY Home Projects | Suitable for users familiar with pneumatic tools |
| 47. Setup Step 1 | Connect air hose securely |
| 48. Setup Step 2 | Add prepared filtered paint |
| 49. Setup Step 3 | Adjust pressure and spray controls |
| 50. Setup Step 4 | Test spray on scrap material |
| 51. Setup Step 5 | Spray with consistent distance and speed |
| 52. Cleaning Frequency | After every use |
| 53. Included Wrench | Multi-function wrench |
| 54. Included Brush | Cleaning brush |
| 55. Included Filter | Air inlet filter |
| 56. Included Connector | G1/4 air connector |
| 57. Instruction Manual | Included |
Simple Operating Workflow
Connect the air supply, fill the cup with prepared paint, set the pressure, test the pattern, and begin painting. Maintain a consistent spray distance and apply thin, even coats for best results.
Note: Final pressure and thinning settings depend on coating type, nozzle size and compressor output. Always follow the coating manufacturer's instructions.
