尺寸 (Size): Approx. length 210 mm, height including cup ~300 mm, cup capacity 600 ml.
重量 (Weight): About 0.9 kg (excluding paint) – lightweight for extended use.
材质 (Material): Alloy body, stainless steel fluid nozzle & needle, plastic paint cup.
供料方式 (Feed Type): Gravity‑feed cup mounted on top of gun.
喷嘴口径 (Nozzle Size): ~1.3 mm (suitable for automotive base/clear coat).
喷雾原理 (Spray Principle): HVLP (High Volume Low Pressure) atomisation for high transfer efficiency and minimal overspray.
空气压力 (Air Pressure): Recommended working pressure ~2.5‑3.0 bar (≈36‑43 psi).
空气消耗 (Air Consumption): Approx. 270 L/min at ~2.0 bar.
喷幅宽度 (Spray Pattern Width): Adjustable, approx. 15‑25 cm at typical distance.
调节功能 (Adjustment Features): Fluid flow adjustment knob, fan width adjustment, air cap pattern control.
喷枪握把 (Handle): Ergonomic pistol‑style trigger for better control in refinishing tasks.
附杯 (Paint Cup): 600 ml transparent plastic cup, detachable for cleaning/refilling.
用途 (Usage Scenes): Automotive refinishing (cars, motorcycles), primers, basecoats, clear coats, furniture refinishing, DIY jobs.
兼容涂料 (Compatible Paint Types): Solvent‑based paints, water‑based paints, varnishes, topcoats, metallic paints.
表面处理 (Finish Quality): Provides smooth, even atomised finish, reduces runs/drips, ideal for achieving professional results.
转移效率 (Transfer Efficiency): High transfer efficiency compared to conventional high‑pressure guns.
可维护性 (Maintenance): Easy disassembly for cleaning.
适合用户 (User Suitability): Both professionals and skilled DIYers; especially good for automotive body shops and refinishing work.
连接接口 (Connection): Standard air inlet (¼″ NPT or similar).
喷距建议 (Recommended Spray Distance): Typically 15‑20 cm from surface.
喷角度 (Spray Angle): Adjustable fan pattern—horizontal, vertical or round.
清洗方便 (Cleaning Convenience): Cup removable, body designed for quick cleaning.
喷枪材质处理 (Material Finish): Mirror polished alloy body to reduce paint build‑up.
涂料兼容 (Paint Viscosity Range): Suitable for typical automotive paint viscosities.
适用场合 (Applicable Surfaces): Metal panels, plastic parts, furniture, woodworking.
环保/低废料 (Eco & Waste Reduction): HVLP reduces paint waste, environmentally friendly.
喷枪控制精准 (Precision Control): Fine control over paint flow, air and pattern.
准备工作 (Setup Requirements): Clean air supply, moisture trap, correct fittings.
安全注意 (Safety Considerations): Adequate ventilation, respirator recommended.
喷枪距离感 (Distance & Motion): Maintain consistent speed/distance for best finish.
喷购建议 (Buying Tips): Select correct nozzle size, verify air compressor capacity.
维修件可得 (Spare Parts Availability): Replacement nozzles, needles, air caps available.
保修/服务 (Warranty & Service): Warranty and parts support recommended.
包装配件 (Package Includes): Spray gun body, paint cup, nozzle/needle set, brush.
适配机型 (Compatible Equipment): Works with standard shop air compressors.
品牌/型号 (Brand & Model): Generic/professional compatible – SATA, Devilbiss, etc.
使用寿命 (Service Life): Long‑lasting with regular cleaning/maintenance.
面漆适应性 (Topcoat Compatibility): Ideal for applying automotive topcoats.
遮蔽控制 (Overspray/Masking): Use masking for clean results in auto body work.
经济效益 (Cost‑Effectiveness): High efficiency reduces paint use and saves time.
